How to write a page using Quarto Markdown

GitHub Pages transforms plain text files into HTML webpages. In this template, files use the .qmd extension and follow Quarto Markdown syntax. Below are examples of the most commonly used formatting structures.

Sections and Subsections

Section headers are created by adding one or more # symbols followed by a space. Typing a single # creates a main section header. Adding more symbols creates deeper hierarchies; for example, typing ## This is a subsection generates a secondary heading. Similarly, using three symbols like ### This is a sub-subsection produces a tertiary heading.

This is a subsection

This is a sub-subsection

To make a section cross-referenceable, append an identifier starting with #sec- to the header. For example, typing ## Mathematical Equations {#sec-maths} allows the section to be referenced anywhere in the document using @sec-maths.

Mathematical Equations

Inline equations, such as \(x^2+y^2=r^2\), are written by enclosing the formula in single $ symbols directly within the text. To write a standalone equation on its own line, enclose the formula in double $$ symbols. To make the equation cross-referenceable, append an identifier to the closing $$. This identifier must strictly begin with the #eq- prefix for Quarto to recognize it as an equation:

$$
  x=\frac{-b\pm \sqrt{b^2-4ac}}{2a} \,,
$$ {#eq-secondorder}

Once processed, the equation is displayed and numbered automatically:

\[ x=\frac{-b\pm \sqrt{b^2-4ac}}{2a} \,, \tag{1}\]

This equation can then be referenced in the text using @eq-secondorder, which automatically renders a clickable link with the appropriate prefix, such as Equation 1.

If the automatic prefix needs to be suppressed, place the reference with a minus sign inside parentheses. For instance, typing (-@eq-secondorder) will suppress the word “Equation” and render just the number in-between parentheses, resulting in (1).

For complex mathematical structures such as systems of equations or multi-line formulas, Quarto supports standard LaTeX inner environments like aligned, split, and gathered within the double $$ blocks. These allow for precise vertical alignment and grouping while sharing a single reference number:

$$
\begin{aligned}
  A &= B + C \\
  X &= Y - Z
\end{aligned}
$$ {#eq-systems}

\[ \begin{aligned} A &= B + C \\ X &= Y - Z \end{aligned} \tag{2}\]

Multi-labeled equations, like the standard LaTeX align environment, are not supported.

Text Formatting and Lists

Text formatting is achieved by enclosing words in asterisks. Using single asterisks produces italic text (e.g. *italic*), while double asterisks produce bold text (e.g. **bold**). One can also display colored text using [red text]{style="color: red;"}, which produces a text in red color.

Unordered lists are created using the - symbol, where the level of indentation determines the hierarchy of the items:

- Level 1 item
  - Level 2 item
    - Level 3 item

This syntax generates the following bulleted list:

  • Level 1 item

    • Level 2 item

      • Level 3 item

Ordered lists use numbers instead of dashes. Typing 1. for every item is sufficient, as the list will automatically number itself correctly upon rendering:

1. First element
1. Second element
1. Third element

The compiled list appears as:

  1. First element

  2. Second element

  3. Third element

Figures and Tables

To insert an image, provide a caption inside square brackets and the file path inside parentheses. A label and display attributes, such as width, can be appended inside curly braces. The label must strictly begin with the #fig- prefix for Quarto to recognize and number the image correctly:

![Default frog picture.](/img/Examples/frog.jpg){#fig-frog width="4cm"}

This places the image in the document, allowing it to be referenced anywhere in the text using @fig-frog (e.g. Figure 1):

Figure 1: Default frog picture.

Tables are constructed using vertical pipes (|) to separate columns and hyphens (-) to divide the header from the content. Colons (:) are added to the divider to control text alignment. A caption and a reference label can be placed at the bottom. The label must strictly begin with the #tbl- prefix for Quarto to recognize and number the table correctly:

| Column 1 | Column 2 | Column 3 |
|:---------|:---------|:---------|
| a        | b        | c        |
| d        | e        | f        |
: Table caption {#tbl-example}

The resulting formatted table can then be referenced using @tbl-example (e.g. Table 1):

Table 1: Table caption

Column 1

Column 2

Column 3

a

b

c

d

e

f

Blockquotes and Callouts

To emphasize a quote, start the line with a > symbol:

> "If it is on the internet... it must be true."
> - Abraham Lincoln

The text is then visually set apart as a blockquote:

“If it is on the internet… it must be true.” - Abraham Lincoln

Quarto Markdown also features Callout Blocks to draw attention to notes, warnings, or tips. These are created by wrapping the text in three colons (:::) and specifying the desired callout type:

:::{.callout-note}
This is a helpful note! The options `.callout-warning`, `.callout-tip`, `.callout-caution`, and `.callout-important` change the color and icon of the box.
:::

The rendered callout box provides a distinct visual element:

Note

This is a helpful note! The options .callout-warning, .callout-tip, .callout-caution, and .callout-important change the color and icon of the box.

Code Snippets

Short, inline code within a sentence is formatted by enclosing the text in single backticks (`). For multi-line code blocks with syntax highlighting, enclose the block in triple backticks and specify the programming language on the first line:

```cpp
float sum (float a, float b) {
  return a + b;
}
```

This displays the code block with the appropriate language-specific coloring:

float sum (float a, float b) {
  return a + b;
}

References

[1]
Reyes Hung M A 2023 Exploration of possible signals beyond special relativity using high-energy astroparticle physics PhD thesis (U. Zaragoza (main))

Footnotes

  1. For example, this is a footnote.↩︎
